Product Overview: TPS60400DBVRG4

The TPS60400DBVRG4 is a high-efficiency, charge pump voltage inverter from Texas Instruments, designed to provide a simple and compact power management solution for applications requiring a negative voltage derived from a positive input voltage. This device is particularly well-suited for battery-powered and low-power applications, where space is at a premium and efficiency is crucial.

Key Features

• Output Voltage: The TPS60400DBVRG4 generates a negative output voltage that is almost equal to the input voltage but inverted, making it ideal for applications that require a dual supply from a single positive rail.
• Efficiency: With a typical efficiency of 80% to 90%, this charge pump converter helps to maximize battery life in portable devices.
• Low Noise: It features a low-output voltage ripple, which is essential for noise-sensitive applications such as audio or precision measurement systems.
• Small Package: Housed in a SOT-23-5 package, the TPS60400DBVRG4 minimizes the footprint on the PCB, allowing for compact circuit design.
• Input Voltage Range: It operates with an input voltage range from 1.6V to 5.5V, accommodating a variety of power sources including single-cell batteries.
• No Inductors: The charge pump design does not require any inductors, which simplifies the circuit design and reduces the overall bill of materials.

Applications

The TPS60400DBVRG4 is versatile and can be used in a wide range of applications, such as:

• Portable devices
• Battery-powered equipment
• Medical instruments
• Operational amplifier power supplies
• Data acquisition systems
• Smartphones and PDAs

Reliability and Quality

Texas Instruments is known for its commitment to quality and reliability, and the TPS60400DBVRG4 is no exception. It is designed to meet the stringent requirements of industrial and consumer applications, ensuring a reliable performance over a wide temperature range.

Overall, the TPS60400DBVRG4 from Texas Instruments is a robust and efficient solution for generating a negative voltage rail in space-constrained and power-sensitive applications.
