Product Overview: TPS61093QDSKRQ1 from Texas Instruments

The TPS61093QDSKRQ1 is a high-performance, fully integrated synchronous boost converter from Texas Instruments, designed specifically for automotive and industrial applications. This device is part of Texas Instruments' reliable power management solutions, providing efficient voltage step-up for electronics that require a higher operating voltage than what is available from the power supply.

Key Features

• Wide Input Voltage Range: The TPS61093QDSKRQ1 operates over a wide input voltage range from 0.8 V to 5.5 V, making it suitable for a variety of low-voltage power sources, including single-cell batteries.
• Adjustable Output Voltage: The output voltage is adjustable from 1.8 V to 12 V, which allows for flexibility in powering different types of circuits and applications.
• High Efficiency: With a synchronous rectifier and a 1.2 MHz fixed switching frequency, the device ensures high efficiency across a wide load range.
• Load Disconnect Feature: The integrated load disconnect feature provides isolation of the load from the power source when the device is disabled, which helps in reducing standby power consumption.
• Protection Features: The TPS61093QDSKRQ1 includes over-temperature protection, over-voltage protection, and under-voltage lockout, ensuring reliable operation under various conditions.
• Automotive Qualified: As a Q1 device, it meets the stringent requirements of the automotive industry, including operation across a wide temperature range of -40°C to 125°C.
• Small Package: Available in a small 6-pin WSON package, it is ideal for space-constrained applications.

Applications

The TPS61093QDSKRQ1 is versatile enough to be used in a range of applications, including but not limited to:

• Automotive infotainment and navigation systems
• Portable and battery-powered electronics
• Industrial control systems
• Power banks and USB-powered devices

With its robust design and comprehensive feature set, the TPS61093QDSKRQ1 is an excellent choice for designers looking to create efficient, reliable, and compact power supply circuits in automotive and industrial environments.
