TPS62067DSGR

Part No TPS62067DSGR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 2A SYNC 8WSON
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.9V
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 6V
Output Current 2A
Frequency - Switching 3MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-WSON (2x2)
Win Source Part Number 034336-TPS62067DSGR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TPS62067
Introduction Date August 01, 2009
Country of Origin Philippines, Philippines
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TPS62067DSGR CAD Model

Description

The TPS62067DSGR is a high-efficiency synchronous step-down converter brought to you by Texas Instruments, a leader in semiconductor solutions. This compact and versatile integrated circuit is designed to meet the power management needs of modern portable and battery-powered applications. With its advanced features and robust performance, the TPS62067DSGR is an ideal choice for engineers looking to optimize power consumption and extend battery life.

Key Features

  • High Efficiency: The device boasts a high efficiency of up to 95%, minimizing energy loss and ensuring maximum battery life.
  • Wide Input Voltage Range: It operates over a wide input voltage range from 2.5V to 6V, accommodating various power sources and system voltages.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to Vin, providing flexibility to power a broad range of components.
  • Compact Size: The TPS62067DSGR comes in a small 2x2mm 8-pin SON package, making it suitable for space-constrained applications.
  • Low Dropout Operation: Its excellent transient response allows low dropout operation, ensuring consistent performance even during voltage fluctuations.
  • Power Save Mode: For improved efficiency at light loads, it features a Power Save Mode that reduces quiescent current.

Applications

This versatile component can be used in a variety of applications, including:

  • Smartphones and Tablets
  • Portable Media Players
  • Wireless LAN and Bluetooth® Devices
  • GPS and Navigation Systems
  • Point-of-Sale Devices

Technical Specifications

Parameter Value
Output Voltage Range 0.8V to Vin
Input Voltage Range 2.5V to 6V
Switching Frequency Up to 2.5MHz
Package 2x2mm 8-pin SON

For detailed information and technical support, please refer to the official Texas Instruments datasheet for the TPS62067DSGR.
