The TPS62131RGTR is a high-efficiency synchronous step-down converter designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This component is part of the TPS6213x family of devices that are optimized for systems requiring a low-voltage power supply from a single Li-Ion battery or from a 3.3V or 5V input rail.

Key Features

• Wide Input Range: The device supports an input voltage range from 3V to 17V, making it versatile for various applications.
• Adjustable Output Voltage: The output voltage is adjustable from 0.9V to 6V, allowing for a wide range of power supply needs.
• High Efficiency: With an efficiency of up to 95%, the TPS62131RGTR minimizes power loss and heat generation, which is crucial for battery-powered devices.
• Compact Design: The device comes in a 16-pin QFN package and requires a minimal number of external components, saving board space and reducing the overall solution size.
• Low Dropout Mode: It operates in 100% duty cycle for low dropout operations, ensuring a continuous power supply even when the input voltage is close to the output voltage.
• Power Save Mode: For light-load efficiency, the TPS62131RGTR features a Power Save Mode that reduces quiescent current and maintains high efficiency over the entire load range.

Applications

The TPS62131RGTR is suitable for a variety of applications including, but not limited to:

• Portable and battery-powered equipment
• Tablets, notebooks, and e-readers
• Data storage systems
• Power supplies for DSPs, FPGAs, and microcontrollers

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The TPS62131RGTR is no exception, as it is built to meet the high standards expected from TI products. It includes thermal shutdown and over-current protection to ensure safe operation under various conditions.

Ordering Information

The TPS62131RGTR is supplied in a tape and reel packaging, which is ideal for automated assembly processes. For detailed product specifications, technical documents, and ordering information, please refer to the Texas Instruments official website or authorized distributors.
