Introducing the TPS65136RTER from Texas Instruments

The TPS65136RTER is a cutting-edge solution designed by Texas Instruments, tailored specifically for powering OLED (Organic Light Emitting Diode) displays. This innovative component is an integral part of TI's extensive portfolio of power management devices, and it offers a compact, efficient, and reliable means of supplying the dual output voltages required by OLED screens.

Key Features of the TPS65136RTER

• Dual Output Voltages: The device is capable of providing a positive output voltage (+Vout) and a negative output voltage (-Vout), both of which are adjustable to accommodate various OLED panels.
• High Efficiency: With an integrated boost converter, the TPS65136RTER achieves high power conversion efficiency, ensuring minimal power loss and extended battery life for portable applications.
• Small Footprint: The component comes in a compact WQFN-16 package, making it an ideal choice for space-constrained applications such as smartphones, digital cameras, and portable media players.
• Low Noise Operation: The device features excellent noise performance, which is critical for maintaining the integrity of the display's visual output.

Applications

The TPS65136RTER is versatile and can be utilized in a wide array of applications where OLED displays are employed. Its main applications include:

• Mobile phones and smartphones
• Portable media players
• Digital cameras
• Handheld gaming devices

Technical Specifications

At the heart of the TPS65136RTER's performance are its technical specifications, which include:

• Input voltage range: 2.7 V to 5.5 V
• Adjustable positive output voltage up to 4.6 V
• Adjustable negative output voltage down to -4.6 V
• 1.6 MHz fixed-frequency PWM operation
• Thermal shutdown and over-current protection

With its robust design and advanced features, the TPS65136RTER from Texas Instruments stands out as a premier solution for powering the next generation of OLED displays, offering designers both performance and reliability in a single package.
