Product Overview: TPS70936DBVT

The TPS70936DBVT is a high-performance, linear regulator offered by Texas Instruments, designed to deliver a stable and precise voltage supply. It is an ideal choice for sensitive applications requiring a low dropout voltage and low quiescent current. This regulator is capable of sourcing a maximum output current of 150 mA while maintaining a low dropout of just 250 mV at full load, which makes it highly efficient for battery-powered devices.

Key Features

• Output Voltage: The device provides a fixed output voltage of 3.6V, ensuring a stable and reliable power supply for your circuits.
• High Accuracy: With an impressive accuracy of ±2%, the TPS70936DBVT ensures precise voltage regulation, which is critical for sensitive components.
• Low Quiescent Current: The ultra-low quiescent current of 1 μA (typical) makes it an excellent choice for battery-operated devices, where power conservation is key.
• Thermal Shutdown and Overcurrent Protection: Built-in safety features protect the device and the application from excessive temperature and current conditions.
• Reverse Current Protection: This feature prevents reverse current flow when the input voltage falls below the output voltage, safeguarding the device and downstream components.

Applications

The TPS70936DBVT is versatile and can be used in a variety of applications, including:

• Portable and battery-powered devices
• Power supply for sensors and analog circuits
• Microcontroller power supply
• Healthcare and medical equipment
• Smart home and IoT devices

Package and Quality

The device comes in a compact SOT-23-5 package, which is suitable for space-constrained applications. The TPS70936DBVT is also supported by Texas Instruments' commitment to quality, ensuring reliable performance and longevity for your products.

With its robust feature set and versatile applications, the TPS70936DBVT from Texas Instruments stands out as a high-quality voltage regulator that meets the needs of modern electronic systems.
