TPS78633DCQR

Part No TPS78633DCQR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 1.5A SOT223-6
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.51V @ 1.5A
Output Current 1.5A
Operating Supply Current 385μA
PSRR 59dB to 32dB (100Hz to 100kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.34V @ 1.5A
Mounting SMD (SMT)
Case / Package SOT-223-6
Win Source Part Number 034812-TPS78633DCQR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS78633DCQR CAD Model

Description

Texas Instruments TPS78633DCQR Voltage Regulator TPS78633DCQR Voltage Regulator

The TPS78633DCQR from Texas Instruments is a highly sophisticated, ultra-low-dropout (LDO) linear voltage regulator designed to deliver superior performance for a wide range of applications. This component is part of Texas Instruments' extensive portfolio of voltage regulation devices, known for their reliability and efficiency.

With an input voltage range from 2.7V to 5.5V, the TPS78633DCQR is versatile enough to accommodate various power sources, making it an ideal choice for battery-powered devices, as well as for more complex electronic systems. The device provides a fixed output voltage of 3.3V, which is a common requirement for many digital and analog circuits, ensuring compatibility with a broad array of components.

One of the standout features of this LDO regulator is its ultra-low dropout voltage, which allows it to maintain a steady output even when the supply voltage is very close to the output voltage. This characteristic is particularly beneficial in battery-operated devices, where maximizing the usage of the available battery voltage is crucial.

The TPS78633DCQR also boasts a high output current capacity of 1.5A, providing sufficient power for demanding applications. Additionally, it includes a range of protective features such as overcurrent protection, thermal shutdown, and reverse polarity protection, safeguarding your circuit against potential damage from abnormal operating conditions.

Designed with a small form factor in mind, the TPS78633DCQR comes in a compact SOT-223 package, which is conducive to space-constrained applications. Its excellent thermal performance ensures that the device operates within its temperature range, maintaining stability and reliability.

Whether you're designing consumer electronics, medical devices, or industrial equipment, the TPS78633DCQR voltage regulator from Texas Instruments provides a high-quality, efficient, and reliable solution for your power management needs.
