Introducing the TPS7B6950QDCYRQ1 from Texas Instruments

The TPS7B6950QDCYRQ1 is a state-of-the-art automotive-grade low-dropout regulator (LDO) designed by Texas Instruments to meet the rigorous demands of modern automotive applications. This advanced component is engineered to provide a stable and reliable power supply, ensuring optimal performance for automotive electronics.

With an impressive input voltage range of 3V to 40V, the TPS7B6950QDCYRQ1 is versatile and capable of handling the fluctuations commonly found in automotive power systems. This makes it an ideal choice for powering sensitive microcontrollers, sensors, and other critical electronic devices within a vehicle.

Key Features

• High Input Voltage Range: Operates from 3V to 40V, accommodating a wide range of battery voltages, including cold-crank and stop-start conditions.
• Stable Output: Delivers a fixed output voltage of 5V, with an impressive accuracy of ±2%, ensuring a stable power supply for sensitive automotive electronics.
• Robust Thermal Performance: Features a wide operating temperature range from -40°C to 150°C, suitable for the harsh thermal environments found in automotive applications.
• Low Dropout: The low dropout voltage ensures efficient operation even when the input voltage is close to the output voltage, reducing power loss and improving overall system efficiency.
• Protection Features: Includes overcurrent protection, thermal shutdown, and undervoltage lockout, enhancing the reliability and safety of the automotive system.
• Small Footprint: Available in a compact 3.5 mm x 3.5 mm SON-10 package, making it ideal for space-constrained applications.

Designed with the automotive environment in mind, the TPS7B6950QDCYRQ1 is AEC-Q100 qualified, reflecting its high reliability and performance under extreme conditions. This LDO is also compliant with the stringent ISO 7637-2 transient immunity standard, ensuring that it can withstand the electrical disturbances encountered in vehicle power supplies.

Whether it's for powertrain systems, body electronics, or infotainment units, the TPS7B6950QDCYRQ1 from Texas Instruments is a perfect power management solution that offers precision, durability, and versatility for the next generation of automotive technology.
