UCC28950PW

Part No UCC28950PW
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description Green Phase-Shifted Full-Bridge Controller With Synchronous Rectification
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Tube
Output Type Transistor Driver
Function Step-Up/Step-Down
Output Configuration Positive
Topology Full-Bridge
Number of Outputs 6
Output Phases 1
Supply Voltage 8 V ~ 17 V
Frequency - Switching 50kHz ~ 1MHz
Duty Cycle (Maximum) 95%
Synchronous Rectifier Yes
Clock Sync Yes
Control Features Dead Time Control, Enable, Frequency Control, Soft Start
Operating Temperature Range -40°C ~ 125°C (TJ)
Package 24-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 24-TSSOP
Win Source Part Number 1276322-UCC28950PW
Manufacturer Homepage www.ti.com
Family Name UCC28950
Introduction Date December 01, 2009
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Quantity per package 60
Ultra Librarian 3D Model Ultra Librarian UCC28950PW CAD Model

Description

UCC28950PW from Texas Instruments is a DC/DC switching controller used in advanced power-conversion designs where engineers need efficient control of external switching stages. Devices in this category are commonly evaluated for telecom power supplies, industrial power systems, server infrastructure, and other high-reliability conversion applications that benefit from flexible controller-based architectures rather than fully integrated regulators. Texas Instruments is widely recognized for power-management solutions, making this part relevant for both new design evaluation and ongoing production support. The current lifecycle status for UCC28950PW is information not available from the provided input, so design and sourcing teams should confirm status directly with Texas Instruments or an authorized distributor before committing to long-term builds. RoHS compliance information is also not available in the provided data. Engineers should verify the latest datasheet, material declaration, and manufacturer compliance documentation before procurement, qualification, or use in regulated markets.
