The XTR116UA/2K5E4 is a highly integrated, 4-20mA current loop transmitter from Texas Instruments. This robust component is designed to seamlessly interface with standard 4-20mA analog signals, which are widely used in industrial control systems for transmitting sensor data over long distances with high immunity to electrical noise.

Key Features

• Integrated Current Loop Driver: The XTR116UA/2K5E4 includes an on-chip voltage-to-current conversion, ensuring smooth and precise control of current loops.
• Low Power Consumption: Optimized for efficient operation, this device is suitable for battery-powered and remote systems where power conservation is critical.
• Enhanced Stability: With built-in protection against reverse battery and over-temperature conditions, the XTR116UA/2K5E4 ensures reliable performance in harsh industrial environments.
• Flexible Power Supply Range: The device operates over a wide supply range, accommodating various application requirements without the need for additional voltage regulation.
• High Accuracy: Precision analog circuit design provides excellent accuracy in current transmission, which is vital for control and monitoring applications.

Applications

The XTR116UA/2K5E4 is suitable for a broad range of industrial applications, including:

• Process control instrumentation
• Factory automation systems
• 4-20mA sensor transmitters
• Remote data acquisition
• Industrial signal conditioning

Quality and Reliability

As with all Texas Instruments products, the XTR116UA/2K5E4 is manufactured to the highest standards of quality and reliability. This device is available in a SOIC-8 package, providing a compact footprint for space-constrained applications. It also features an extended temperature range, making it suitable for outdoor and industrial temperature environments.

Ordering Information

The XTR116UA/2K5E4 is available in tape and reel packaging, facilitating easy integration into automated manufacturing processes. For detailed ordering and shipping information, consult the Texas Instruments website or contact authorized distributors.
