TLP118 Toshiba Semiconductor and Storage TLP118 real image TLP118 real image7439 TLP118 real image7440 TLP118 Real Image1 TLP118 Real Image2 TLP118 label picture
Same model may have multiple batches, images only for reference.
TLP118 Toshiba Semiconductor and Storage TLP118 real image TLP118 real image7439 TLP118 real image7440 TLP118 Real Image1 TLP118 Real Image2 TLP118 label picture
TLP118 Toshiba Semiconductor and Storage TLP118 real image TLP118 real image7439 TLP118 real image7440 TLP118 Real Image1 TLP118 Real Image2 TLP118 label picture
Same model may have multiple batches, images only for reference.

TLP118

Part No TLP118
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL SO6-5
Datasheet
TLP118 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Input Type DC
Output Type Open Collector
Channel Output Current 25mA
Data Rate 20Mbps
Propagation Delay tpLH / tpHL (Max) 60ns, 60ns
Rise and Fall Time 30ns, 30ns
Forward Voltage 1.61V
Continuous forward current- Max 25mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 6-SO, 5 Lead
Win Source Part Number 092705-TLP118
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLP118 CAD Model

Description

Toshiba Semiconductor and Storage offers the 092705-TLP118, a reliable and efficient isolator with a range of features.

  • Data rate: 20Mbps
  • Forward voltage: 1.61V
  • Isolation voltage: 3750Vrms
  • Common mode transient immunity: 15kV/μs
  • Propagation delay tpLH / tpHL (Max): 60ns and 60ns
  • Channel output current: 25mA
  • Continuous forward current: 25mA
  • Supply and demand status: limited
  • Popularity rating: high
  • Win Source Part Number: 092705-TLP118
