TLP290-4GB

Name: TLP290-4GB
Brand: Toshiba Semiconductor and Storage
SKU: 370326
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP290-4GB
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optocoupler AC-IN 4-CH Transistor DC-OUT 16-Pin SO T/R / Optoisolator Transistor Output 2500Vrms 4 Channel 16-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Transistor, Photovoltaic Output
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel(TR)
Number of Channels	4
Voltage - Isolation	2500Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	400% @ 5mA
Turn On / Turn Off Time (Typ)	3μs, 3μs
Rise / Fall Time (Typ)	2μs, 3μs
Input Type	AC, DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	50mA
Vce Saturation (Max)	400mV
Operating Temperature Range	-55°C ~ 110°C
Mounting Style	SMD/SMT
Package	16-SOIC (0.179", 4.55mm Width)
Manufacturer Device Package	16-SO
Win Source Part Number	218167-TLP290-4GB
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	TLP290-4
ECCN	EAR99
Country of Origin	Thailand
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian TLP290-4GB CAD Model

Alternative Products

Description

The TLP290-4GB is an optoisolator manufactured by Toshiba Semiconductor and Storage.
