TLP290(BL-TP,SE Toshiba Semiconductor and Storage TLP290(BL-TP,SE Real Image
Same model may have multiple batches, images only for reference.
TLP290(BL-TP,SE Toshiba Semiconductor and Storage TLP290(BL-TP,SE Real Image
TLP290(BL-TP,SE Toshiba Semiconductor and Storage TLP290(BL-TP,SE Real Image
Same model may have multiple batches, images only for reference.

TLP290(BL-TP,SE

Part No TLP290(BL-TP,SE
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 4-SO  /  Optoisolator Transistor Output 3750Vrms 1 Channel 4-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Optoisolators - Transistor, Photovoltaic Output
Mfr Toshiba Semiconductor and Storage
Package Tape & Reel
Number of Channels 1
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Min) 200% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Turn On / Turn Off Time (Typ) 3µs, 3µs
Rise / Fall Time (Typ) 2µs, 3µs
Input Type AC, DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.25V
Current - DC Forward (If) (Max) 50 mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C ~ 110°C
Mounting SMD (SMT)
Package / Case 4-SOIC (0.179", 4.55mm Width)
Supplier Device Package 4-SO
Base Product Number TLP290
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Other Names TLP290(BL-TPSECT,TLP290(BL-TPSE(TCT,TLP290(BL-TPSEDKR,TLP290BLTPSE,TLP290(BL-TPSE(TCT-ND,TLP290(BL-TP,SETR,TLP290(BL-TPSE(TTR-ND,TLP290(BL-TPSETR,TLP290(BL-TPSE(TTR,TLP290(BL-TP,SE(T,TLP290BLTPSET,TLP290(BL-TPSE(TDKR,TLP290(BL-TPSE(TDKR-ND
Standard Package 2,500
Win Source Part Number 1099900-TLP290(BL-TP,SE
Ultra Librarian 3D Model Ultra Librarian TLP290(BL-TP,SE CAD Model

Description

The TLP290(BL-TP,SE is an optoisolator transistor output that features a high isolation voltage of 3750Vrms.

  • Maximum Forward Current: 50mA
  • Voltage Forward: 1.25V
  • Rise Time: 2μs
  • Fall Time: 3μs
  • Channels: Single-channel
  • Output Type: Transistor
  • Input Type: AC/DC
  • Current Transfer Ratio: 200% @ 5mA
  • Maximum Voltage Output: 80V
  • Package: 4-SOIC
  • Operating Temperature: -55°C to 110°C
