TLP521-1

Name: TLP521-1
Brand: Toshiba Semiconductor and Storage
SKU: 370486
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	TLP521-1
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optoisolator Transistor Output 5300Vrms 2 Channel 8-DIP
Datasheet	TLP521-1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Transistor, Photovoltaic Output
Manufacturer	Isocom Components 2004 LTD
Packaging	Tube
Part Status	Active
Number of Channels	2
Voltage - Isolation	5300Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	600% @ 5mA
Rise / Fall Time (Typ)	4μs, 3μs
Input Type	DC
Output Type	Transistor
Voltage - Output (Max)	55V
Voltage - Forward (Vf) (Typ)	1.15V
Current - DC Forward (If) (Max)	50mA
Vce Saturation (Max)	400mV
Operating Temperature Range	-30°C ~ 100°C
Mounting Style	Through Hole
Package	8-DIP (0.300", 7.62mm)
Manufacturer Device Package	8-DIP
Win Source Part Number	218244-TLP521-1
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Industrial, Communications & Networking
Ultra Librarian 3D Model	Ultra Librarian TLP521-1 CAD Model

Alternative Products

Description

The TLP521-1 is a photovoltaic output transistor optoisolator from Isocom Components 2004 LTD.

Package: 8-DIP (0.300", 7.62mm)
Mounting: through-hole
Operating temperature range: -30°C to 100°C
Compliance: RoHS regulations
Applications: industrial, communications, and networking applications.
Voltage isolation: 5300Vrms
Current transfer ratio (Min): 100% @ 5mA
Maximum forward voltage: 1.15V
Vce saturation (Max): 400mV
