Same model may have multiple batches, images only for reference.

TMH 0505S

Name: TMH 0505S
Brand: Traco Power
SKU: 1336089
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TMH 0505S
Manufacturer	Traco Power
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 2W / Isolated Module DC DC Converter 1 Output 5V 400mA 5V - 5.5V Input
Datasheet	TMH 0505S Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Manufacturer	Traco Power
Packaging	Tube
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	5V
Voltage - Input (Max)	5.5V
Voltage - Output 1	5V
Current - Output (Max)	400mA
Power (Watts)	2 W
Voltage - Isolation	1 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	76%
Mounting	Through Hole
Case / Package	7-SIP Module, 4 Leads
Size / Dimension	0.94" L x 0.54" W x 0.31" H (23.8mm x 13.7mm x 8.0mm)
Base Product Number	TMH 0505
RoHS Status	ROHS3 Compliant
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Other Part Number	1951-2668
Standard Package	10
Win Source Part Number	1336089-TMH 0505S
Ultra Librarian 3D Model	Ultra Librarian TMH 0505S CAD Model

Alternative Products

Description

The Traco Power TMH 0505S is a DC DC converter that is used in ITE (commercial) applications.

Type: Isolated module type
Features: SCP features
Size and Dimension: 0.94" L x 0.54" W x 0.31" H (23.8mm x 13.7mm x 8.0mm)
Power Output: 2 W
Voltage Isolation: 1 kV
Input Voltage: 5V to 5.5V
Output Voltage: 5V
Efficiency: 76%
Temperature Range: -40°C to 85°C (With Derating)
