Same model may have multiple batches, images only for reference.
EKMG250ELL682MMP1S Real Image
Same model may have multiple batches, images only for reference.

EKMG250ELL682MMP1S

Part No EKMG250ELL682MMP1S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 6800UF 20% 25V RADIAL / 6800 µF 25 V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series KMG
Package Bulk
Capacitance 6800 µF
Tolerance ±20%
Voltage - Rated 25 V
Lifetime @ Temp. 1000 Hrs @ 105°C
Temperature Range - Operating -55°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 2.04 A @ 120 Hz
Ripple Current @ High Frequency 2.2032 A @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Dimension 0.709" Dia (18.00mm)
Height - Seated (Max) 1.457" (37.00mm)
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Other Names 565-1315
Standard Package 250
Win Source Part Number 1013877-EKMG250ELL682MMP1S
Ultra Librarian 3D Model Ultra Librarian EKMG250ELL682MMP1S CAD Model

Description

The United Chemi-Con KMG series aluminum electrolytic capacitor is a reliable and cost-effective solution for general-purpose applications.

  • Capacitance: 6800 µF
  • Voltage Rating: 25 V
  • Model: EKMG250ELL682MMP1S
  • Package: Radial, can
  • Lead Spacing: 0.295 inches
  • Height: 1.457 inches
  • Diameter: 0.709 inches
  • Lifetime: 1000 hours @ 105°C
  • Ripple Current (Low Frequency): 2.04 A @ 120 Hz
  • Ripple Current (High Frequency): 2.2032 A @ 100 kHz
  • Polarized: Yes
  • Tolerance: ±20%
  • Mounting: Through-hole
  • REACH: Unaffected
  • ECCN: EAR99
