115CNQ015ASM Real Image
Same model may have multiple batches, images only for reference.

115CNQ015ASM

Part No 115CNQ015ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 15V D618SM  /  Diode Array 1 Pair Common Cathode Schottky 15 V 55A Through Hole D-61-8-SM
Datasheet
115CNQ015ASM Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Vishay General Semiconductor - Diodes Division
Package Bulk
Product Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 15 V
Current - Average Rectified (Io) (per Diode) 55A
Voltage - Forward (Vf) (Max) @ If 370 mV @ 55 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 20 mA @ 15 V
Operating Temperature - Junction -55°C ~ 125°C
Mounting Type Through Hole
Package / Case D-61-8-SM
Supplier Device Package D-61-8-SM
Base Product Number 115CNQ015
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names *115CNQ015ASM
Standard Package 400
Win Source Part Number 1008051-115CNQ015ASM
Ultra Librarian 3D Model Ultra Librarian 115CNQ015ASM CAD Model

Description

The 115CNQ015ASM from Vishay General Semiconductor - Diodes Division is a diode rectifier array designed for various applications, including power supplies, DC/DC converters, and motor drives.

  • Package: D-61-8-SM
  • Standard Package: 400
  • Mounting: Through-Hole
  • Maximum Reverse Voltage: 15V
  • Maximum Forward Voltage: 370mV @ 55A
  • Average Rectified Current: 55A
  • Junction Temperature Range: -55°C to 125°C
