85CNQ015ASM Real Image
Same model may have multiple batches, images only for reference.

85CNQ015ASM

Part No 85CNQ015ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description SCHOTTKY RECTIFIER New GenIII D-61 Package | DIODE ARRAY SCHOTTKY 15V D618SM
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 15V
Current - Average Rectified (Io) (per Diode) 40A
Voltage - Forward (Vf) (Maximum) at If 450mV at 80A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 20mA at 15V
Operating Temperature - Junction -55°C ~ 125°C
Mounting Style Through Hole
Manufacturer Package D-61-8-SM
Supplier Device Package D-61-8-SM
Family Part Number 85CNQ015
Manufacturer Pack Quantity 400
MSL Level 1 (Unlimited)
Win Source Part Number 1134039-85CNQ015ASM
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 85CNQ015ASM CAD Model

Description

The 85CNQ015ASM is a Schottky diode from Vishay Semiconductor Diodes Division.

  • Speed: 200mA (Io)
  • Diode Configuration: 1 pair common cathode
  • Current Average Rectified (Io) per Diode: 40A
  • Voltage Forward (Vf) (maximum) @ If: 450mV @ 80A
  • Voltage - DC Reverse (Vr) (maximum): 15V
  • Package: D-61-8-SM
  • Mounting: Through-hole
  • Operating Temperature: -55°C to 125°C
  • MSL Level: 1 (unlimited)
  • Manufacturer Pack Quantity: 400
