B340A-E3/61T Vishay B340A-E3/61T Real Image B340A-E3/61T real image B340A-E3/61T real image2365 B340A-E3/61T real image2366
Same model may have multiple batches, images only for reference.
B340A-E3/61T Vishay B340A-E3/61T Real Image B340A-E3/61T real image B340A-E3/61T real image2365 B340A-E3/61T real image2366
B340A-E3/61T Vishay B340A-E3/61T Real Image B340A-E3/61T real image B340A-E3/61T real image2365 B340A-E3/61T real image2366
Same model may have multiple batches, images only for reference.

B340A-E3/61T

Part No B340A-E3/61T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 3A DO214AC
Datasheet
B340A-E3/61T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 550mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 40V
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -65°C to 150°C
Win Source Part Number 000052-B340A-E3/61T
Family Name B340A
Introduction Date December 08, 2003
ECCN EAR99
Country of Origin China
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian B340A-E3/61T CAD Model

Description

B340A-E3/61T Schottky Rectifier

The B340A-E3/61T is a Schottky rectifier that provides excellent efficiency and effectiveness in circuit designs with its low forward voltage and high surge capability.

  • Applications:
    • Switch Mode Power Supplies
    • High-frequency Inverters
    • Freewheeling Applications
  • Features and Benefits:
    • High Surge Current Capability
    • Low Power Loss
    • Compact Package for Space Efficiency
  • Additional Details:
    • Forward Voltage: 0.5V
    • Average Forward Current: 3A
    • Package: DO-214AA (SMB)
