DG409LDY-T1-E3 Vishay DG409LDY-T1-E3 Real Image DG409LDY-T1-E3 real image
Same model may have multiple batches, images only for reference.
DG409LDY-T1-E3 Vishay DG409LDY-T1-E3 Real Image DG409LDY-T1-E3 real image
DG409LDY-T1-E3 Vishay DG409LDY-T1-E3 Real Image DG409LDY-T1-E3 real image
Same model may have multiple batches, images only for reference.

DG409LDY-T1-E3

Part No DG409LDY-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MUX CMOS ANG DUAL 8CH 16SOIC / Analog Multiplexer Dual 4:1 16-Pin SOIC N T/R
Datasheet
DG409LDY-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Switch Circuit SP4T
Number of Circuits 2
Max On Resistance 29 Ohm
Channel-to-Channel Matching (ΔRon) 1 Ohm
Single Supply Voltage (V+) 2 V to 12 V
Dual Supply Voltage(V±) ±3 V to 6 V
Max Switch Time (Ton,Toff) 55ns, 25ns
Charge Injection 1pC
Channel Capacitance(CS off, CD off) 7pF, 20pF
Max Leakage Current (IS off) 1nA
Crosstalk -82dB @ 100kHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SOIC
Win Source Part Number 1033247-DG409LDY-T1-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name DG409L
Introduction Date January 08, 2001
ECCN EAR99
Country of Origin Philippines, Taiwan
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian DG409LDY-T1-E3 CAD Model

Description

The Vishay DG409LDY-T1-E3 is a SP4T switch circuit integrated circuit manufactured by Vishay.

  • Mounting: Surface-mount device
  • Popularity: High
  • Circuits: Two circuits
  • Channel-to-channel Matching: 1 Ohm
  • Temperature Range: -40°C to 85°C
  • Status: Obsolete and end-of-life
  • Win Source Part Number: 1033247-DG409LDY-T1-E3
