GSOT05C-E3-08

Part No GSOT05C-E3-08
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS DIODE 5VWM 16VC SOT23
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 2
STAND-OFF Voltage (Vwm) 5V (Max)
Minimum Breakdown Voltage 6V
Max Clamping Voltage 16V
Peak Pulse Current(Ippm) 30A (8/20μs)
Power Dissipation - Pd 480W
Applications General Purpose
Capacitance @ Frequency 260pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 016754-GSOT05C-E3-08
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name GSOT05C
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian GSOT05C-E3-08 CAD Model

Description

GSOT05C-E3-08 from Vishay is a TVS diode intended for circuit protection roles where sensitive electronics may be exposed to transient voltage events such as ESD, EFT, or other surge conditions. In practical designs, components in this category are commonly considered for protecting data lines, interface ports, consumer electronics, industrial control inputs, and compact embedded systems where board space and response speed matter. For engineers, the value of a TVS device like this is its role in improving system robustness and helping reduce field failures caused by electrical overstress. Because the provided lifecycle status is unknown, procurement and design teams should confirm current manufacturer status before committing to new production builds or long-term service programs. RoHS compliance information is not available in the provided data, so environmental compliance should also be verified through the official Vishay datasheet, declaration, or authorized distributor documentation before qualification or shipment into regulated markets.
