Same model may have multiple batches, images only for reference.

IHSM7832ER100L

Name: IHSM7832ER100L
Brand: Vishay
SKU: 811601
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IHSM7832ER100L
Manufacturer	Vishay
Catalog	Fixed Inductors
Description	FIXED IND 10UH 5A 36 MOHM SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Vishay Dale
Packaging	Reel
Material - Core	Ferrite
Inductance	10μH
Tolerance	±15%
Current Rating (Amps)	5A
Current - Saturation	1.7A
Shielding	Unshielded
DC Resistance (DCR)	36mOhm Max
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	1kHz
Mounting Style	SMD
Manufacturer Package	Nonstandard
Dimension	0.840" L x 0.320" W (21.34mm x 8.13mm)
Height - Seated (Maximum)	0.285" (7.24mm)
Manufacturer Pack Quantity	500
MSL Level	1 (Unlimited)
Popularity	Low
Supply and Demand Status	Limited
Win Source Part Number	811604-IHSM7832ER100L
Ultra Librarian 3D Model	Ultra Librarian IHSM7832ER100L CAD Model

Alternative Products

Description

The Vishay Dale IHSM7832ER100L is a surface mount inductor.

Core: Ferrite
Inductance: 10μH
Tolerance: ±15%
Saturation Current: 1.7A
DC Resistance: 36mOhm max
Dimensions: 0.840" L x 0.320" W (21.34mm x 8.13mm)
Packaging: Reel
