IMC1812ER2R2K

Name: IMC1812ER2R2K
Brand: Vishay
SKU: 1382306
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	IMC1812ER2R2K
Manufacturer	Vishay
Catalog	Fixed Inductors
Description	FIXED IND 2.2UH 380MA 700MOHM SM / 2.2 µH Unshielded Drum Core, Wirewound Inductor 380 mA 700mOhm Max 1812 (4532 Metric)
Datasheet	IMC1812ER2R2K Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Vishay
Series	IMC-1812
Package	Tape & Reel (TR)
Type	Drum Core, Wirewound
Material - Core	Iron Powder
Inductance	2.2 µH
Tolerance	±10%
Current Rating (Amps)	380 mA
Current - Saturation (Isat)	-
Shielding	Unshielded
DC Resistance (DCR)	700mOhm Max
Q @ Freq	50 @ 7.96MHz
Frequency - Self Resonant	55MHz
Ratings	-
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	7.96 MHz
Mounting Type	Surface Mount
Package / Case	1812 (4532 Metric)
Supplier Device Package	1812
Size / Dimension	0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)	0.134" (3.40mm)
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Standard Package	500 pcs
Win Source Part Number	1382306-IMC1812ER2R2K
Ultra Librarian 3D Model	Ultra Librarian IMC1812ER2R2K CAD Model

Alternative Products

Description

The IMC1812ER2R2K is a fixed inductor with a drum core and wirewound construction, designed for various electronic applications.

Inductance: 2.2µH
Current Rating: 380mA
Package: 1812
Mounting: Surface Mount
Core Type: Drum Core
Shielding: Unshielded
Tolerance: ±10%
Manufacturer: Vishay
Application: Power supplies, DC-DC converters, and filter circuits
