IRFB20N50KPBF Vishay IRFB20N50KPBF Real Image IRFB20N50KPBF real image
Same model may have multiple batches, images only for reference.
IRFB20N50KPBF Vishay IRFB20N50KPBF Real Image IRFB20N50KPBF real image
IRFB20N50KPBF Vishay IRFB20N50KPBF Real Image IRFB20N50KPBF real image
Same model may have multiple batches, images only for reference.

IRFB20N50KPBF

Part No IRFB20N50KPBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 500V 20A TO-220AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 500V
Continuous Drain Current at 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 110nC @ 10V
Max Input Capacitance 2870pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 280W (Tc)
Maximum Rds On at Id,Vgs 250 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 089715-IRFB20N50KPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFB20N50KPBF CAD Model

Description

The Vishay 089715-IRFB20N50KPBF MOSFET is an N-Channel power transistor that has a maximum power dissipation of 280W at case temperature.

  • Drive Voltage: 10V
  • Drain-Source Breakdown Voltage: 500V
  • Continuous Drain Current at 25°C: 20A (Tc)
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Package: TO-220AB
  • Mounting: through-hole
  • Category: Discrete Semiconductor Products
  • Status: active
  • Supply and Demand Status: balanced
