IRFBG30PBF Vishay IRFBG30PBF Real Image IRFBG30PBF real image IRFBG30PBF real image333
Same model may have multiple batches, images only for reference.
IRFBG30PBF Vishay IRFBG30PBF Real Image IRFBG30PBF real image IRFBG30PBF real image333
IRFBG30PBF Vishay IRFBG30PBF Real Image IRFBG30PBF real image IRFBG30PBF real image333
Same model may have multiple batches, images only for reference.

IRFBG30PBF

Part No IRFBG30PBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 1000V 3.1A TO-220AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 1000V (1kV)
Continuous Drain Current at 25°C 3.1A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 80nC @ 10V
Max Input Capacitance 980pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 125W (Tc)
Maximum Rds On at Id,Vgs 5 Ohm @ 1.9A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 017587-IRFBG30PBF
Family Name IRFBG30
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Audio, Signal Processing, Industrial
Ultra Librarian 3D Model Ultra Librarian IRFBG30PBF CAD Model

Description

The electronic component with Id 167525 is a MOSFET manufactured by Vishay.

  • Win Source Part Number: 017587-IRFBG30PBF
  • Mounting Technology: through-hole
  • Family: IRFBG30
  • Category: Discrete Semiconductor Products
  • Maximum Power Dissipation: 125W (Tc)
  • Drain-Source Breakdown Voltage: 1000V (1kV)
  • Continuous Drain Current @ 25°C: 3.1A (Tc)
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Rds On @ Id, Vgs: 5 Ohm @ 1.9A, 10V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Gate Charge: 80nC @ 10V
  • Maximum Input Capacitance: 980pF @ 25V
  • Supply and Demand Status: sufficient
  • Applications: commonly used in audio, signal processing, and industrial applications
