IRFI9640GPBF Real Image IRFI9640GPBF real image338
Same model may have multiple batches, images only for reference.
IRFI9640GPBF Real Image IRFI9640GPBF real image338
IRFI9640GPBF Real Image IRFI9640GPBF real image338
Same model may have multiple batches, images only for reference.

IRFI9640GPBF

Part No IRFI9640GPBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 200V 6.1A TO220FP
Datasheet
IRFI9640GPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 6.1A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 44nC @ 10V
Max Input Capacitance 1200pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 40W (Tc)
Maximum Rds On at Id,Vgs 500 mOhm @ 3.7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220-3
Dimension TO-220-3 Full Pack, Isolated Tab
Win Source Part Number 069488-IRFI9640GPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRFI9640GPBF CAD Model

Description

This electronic component is a MOSFET from the manufacturer Vishay.

  • Part Number: 069488-IRFI9640GPBF
  • Polarity: P-Channel
  • Maximum Power Dissipation: 40W (Tc)
  • Drive Voltage: 10V
  • Temperature Range: -55°C to 150°C (TJ)
  • Case/Package: TO-220-3
  • Dimension: TO-220-3 Full Pack, Isolated Tab
  • Drain-Source Breakdown Voltage: 200V
  • Continuous Drain Current: 6.1A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 44nC @ 10V
  • Maximum Input Capacitance: 1200pF @ 25V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On: 500 mOhm @ 3.7A, 10V
