Same model may have multiple batches, images only for reference.

IRFP32N50K

Name: IRFP32N50K
Brand: Vishay
SKU: 605096
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	IRFP32N50K
Manufacturer	Vishay
Catalog	FETs - Single
Description	Power MOSFET(Vdss=500V, Rds(on)typ.=0.135ohm, Id=32A) \| MOSFET N-CH 500V 32A TO-247AC
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Siliconix
Packaging	Tube
Status	Obsolete
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	500V
Id - Continuous Drain Current	32A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	160mOhm at 32A, 10V
Gate Source Voltage(th) (Maximum) at Id	5V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	190nC at 10V
Gate Source Voltage (Maximum)	±30V
Input Capacitance (Ciss) (Maximum) at Vds	5280pF at 25V
Power Dissipation (Maximum)	460W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	Through Hole
Supplier Device Package	TO-247-3
Manufacturer Package	TO-247-3
Manufacturer Pack Quantity	500
MSL Level	1 (Unlimited)
Win Source Part Number	1187784-IRFP32N50K
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRFP32N50K CAD Model

Alternative Products

Description

The Vishay Siliconix electronic component is a MOSFET technology-based device with N-channel transistor polarity.

Supply and Demand Status: Limited
Status: Obsolete
Manufacturer Homepage: www.irf.com
Win Source Part Number: 1187784-IRFP32N50K
Supplier Device Package: TO-247-3
Gate Source Voltage(th) (Maximum) @ Id: 5V @ 250μA
