LL103A-GS08 Vishay LL103A-GS08 Real Image LL103A-GS08 label picture
Same model may have multiple batches, images only for reference.
LL103A-GS08 Vishay LL103A-GS08 Real Image LL103A-GS08 label picture
LL103A-GS08 Vishay LL103A-GS08 Real Image LL103A-GS08 label picture
Same model may have multiple batches, images only for reference.

LL103A-GS08

Part No LL103A-GS08
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 200MA SOD80
Datasheet
LL103A-GS08 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 600mV @ 200mA
Reverse Recovery Time (trr) 10ns
Current - Reverse Leakage @ Vr 5μA @ 30V
Capacitance @ Vr, F 50pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-80 MiniMELF
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 018621-LL103A-GS08
Family Name LL103A
Introduction Date April 02, 1998
ECCN EAR99
Country of Origin China
Halogen Free Unknown
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Safety, Signal Processing, Automotive
Ultra Librarian 3D Model Ultra Librarian LL103A-GS08 CAD Model

Description

The Vishay LL103A-GS08 is a Schottky diode that belongs to the discrete semiconductor products family.

  • Specifications: The Vishay LL103A-GS08 diode offers a voltage of 40V and a current of 200mA.
  • Applications: It is suitable for use in power management, safety, signal processing, and automotive applications.
  • Package: This diode is available in SOD-80 MiniMELF case/package.
