MUR3020WT Real Image MUR3020WT real image15842
Same model may have multiple batches, images only for reference.
MUR3020WT Real Image MUR3020WT real image15842
MUR3020WT Real Image MUR3020WT real image15842
Same model may have multiple batches, images only for reference.

MUR3020WT

Part No MUR3020WT
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 200V 15A TO247AC / 30 Amp Super Fast Recovery Rectifier 200 to 600 Volts
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Vishay Semiconductor Diodes Division
Packaging Tube
Part Status Obsolete (End Of Life)
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 200V
Current - Average Rectified (Io) (per Diode) 15A
Voltage - Forward (Vf) (Maximum) at If 1.05V at 15A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 35ns
Current - Reverse Leakage at Vr 10μA at 200V
Operating Temperature - Junction -65°C ~ 175°C
Mounting Style Through Hole
Manufacturer Package TO-247-3
Supplier Device Package TO-247AC
Part Number Series MUR3020WT
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 811145-MUR3020WT
Ultra Librarian 3D Model Ultra Librarian MUR3020WT CAD Model

Description

The MUR3020WT is a fast recovery diode manufactured by Vishay Semiconductor Diodes Division.

  • Diode Type: Standard
  • Reverse Recovery Time: 35ns
  • Diode Configuration: 1 Pair Common Cathode
  • Maximum DC Reverse Voltage: 200V
  • Average Rectified Current: 15A
  • Temperature Range: -65°C to 175°C
  • Package: TO-247AC
