S1MHE3/61T Real Image S1MHE3/61T Real Image
Same model may have multiple batches, images only for reference.
S1MHE3/61T Real Image S1MHE3/61T Real Image
S1MHE3/61T Real Image S1MHE3/61T Real Image
Same model may have multiple batches, images only for reference.

S1MHE3/61T

Part No S1MHE3/61T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 1KV 1A DO214AC / Diode Switching 1KV 1A Automotive 2-Pin SMA T/R
Datasheet
S1MHE3/61T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1000V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) 1.8μs
Current - Reverse Leakage @ Vr 5μA @ 1000V
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 1093474-S1MHE3/61T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Consumer Electronics, Automotive, Communications & Networking
Family Name S1M
Introduction Date June 23, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian S1MHE3/61T CAD Model

Description

The Vishay 423291 is a standard diode with a maximum reverse voltage of 1000V and an average rectified current of 1A.

  • Maximum Reverse Voltage: 1000V
  • Average Rectified Current: 1A
  • Forward Voltage: 1.1V @ 1A
  • Reverse Recovery Time: 1.8μs
  • Reverse Leakage Current: 5μA @ 1000V
  • Capacitance: no capacitance specification
  • Mounting Technology: SMD
  • Package: DO-214AC (SMA) package
  • Temperature Range: -55°C to 150°C
  • Suitable for use in: discrete semiconductor products
  • Status: obsolete
  • Popularity: high popularity
  • Supply and Demand Status: sufficient
