Same model may have multiple batches, images only for reference.

SI9407BDY-T1-E3

Name: SI9407BDY-T1-E3
Brand: Vishay
SKU: 513097
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI9407BDY-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH 60V 4.7A 8-Pin SOIC N T/R / MOSFET P-CH 60V 4.7A 8-SOIC
Datasheet	SI9407BDY-T1-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	4.7A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	22nC @ 10V
Max Input Capacitance	600pF @ 30V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.4W (Ta), 5W (Tc)
Maximum Rds On at Id,Vgs	120 mOhm @ 3.2A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	1096347-SI9407BDY-T1-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	Si9407BDY
Introduction Date	February 04, 2008
ECCN	EAR99
Country of Origin	China
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian SI9407BDY-T1-E3 CAD Model

Alternative Products

Description

The Vishay SI9407BDY-T1-E3 is a P-Channel MOSFET.

Drain-Source Breakdown Voltage: 60V
Continuous Drain Current: 4.7A (Tc)
Gate-Source Threshold Voltage: 3V @ 250μA
Maximum Gate Charge: 22nC @ 10V
Maximum Rds On @ Id,Vgs: 120 mOhm @ 3.2A, 10V
Package: 8-SOIC (0.154", 3.90mm Width)
Mounting: Surface mountable
Operating Temperature: -55°C to 150°C (TJ)
Standard Package: Reel - TR
Dimensions: 8-SOIC (0.154", 3.90mm Width)
