Same model may have multiple batches, images only for reference.

SIA519EDJ-T1-GE3

Name: SIA519EDJ-T1-GE3
Brand: Vishay
SKU: 513131
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SIA519EDJ-T1-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N/P-CH 20V 4.5A SC70-6
Datasheet	SIA519EDJ-T1-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
FET Type	N and P-Channel
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	4.5A
Maximum Rds On at Id,Vgs	40 mOhm @ 4.2A, 4.5V
Gate-Source Threshold Voltage	1.4V @ 250μA
Max Gate Charge	12nC @ 10V
Max Input Capacitance	350pF @ 10V
Maximum Power Dissipation	7.8W
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	PowerPAK SC-70-6 Dual
Win Source Part Number	1096381-SIA519EDJ-T1-GE3
Popularity	Medium
Supply and Demand Status	Limited
Application Field	Used in Industrial, Power Management
Ultra Librarian 3D Model	Ultra Librarian SIA519EDJ-T1-GE3 CAD Model

Alternative Products

Description

The Vishay SiA519EDJ-T1-GE3 is a logic level gate N and P-channel FET transistor.

Power Dissipation: 7.8W
Maximum Gate Charge: 12nC @ 10V
Popularity: Medium
Supply and Demand: Limited
Application: Industrial Power Management
Package: PowerPAK SC-70-6 Dual
