The ThunderFET® series MOSFET (Metal Oxide) electronic component is designed for N-Channel FET type.

• Maximum Drain to Source Voltage (Vdss): 200V
• Continuous Drain Current: 18.6A (Tc) @ 25°C
• Maximum Rds On (Max) @ Id, Vgs: 60mOhm @ 10A, 10V
• Gate Charge (Qg) (Max) @ Vgs: 23 nC @ 7.5 V
• Input Capacitance (Ciss) (Max) @ Vds: 1110 pF @ 100 V
• Temperature Range: -55°C ~ 150°C (TJ)
• Maximum Power Dissipation: 52W (Tc)
• Package / Case: PowerPAK® SO-8
• Supplier Device Package: PowerPAK® SO-8
• Drive Voltage (Max Rds On, Min Rds On): 7.5V, 10V
