Same model may have multiple batches, images only for reference.

SUD19N20-90-E3

Name: SUD19N20-90-E3
Brand: Vishay
SKU: 349112
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SUD19N20-90-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 200V 19A DPAK
Datasheet	SUD19N20-90-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	200V
Continuous Drain Current at 25°C	19A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	51nC @ 10V
Max Input Capacitance	1800pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3W (Ta), 136W (Tc)
Maximum Rds On at Id,Vgs	90 mOhm @ 5A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-252, (D-Pak)
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	031607-SUD19N20-90-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	SUD19N20-90
Introduction Date	February 25, 2004
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian SUD19N20-90-E3 CAD Model

Alternative Products

Description

The Vishay 031607-SUD19N20-90-E3 is a high popularity N-channel MOSFET that is balanced in supply and demand.

Function: Designed to switch and amplify electronic signals and is commonly used in power supply circuits.
Maximum Drain-Source Breakdown Voltage: 200V
Maximum Continuous Drain Current: 19A
Manufacturer: Vishay, a leading company in the semiconductor industry that is known for producing high-quality and reliable electronic components.
