Same model may have multiple batches, images only for reference.

SUD50P08-25L-E3

Name: SUD50P08-25L-E3
Brand: Vishay
SKU: 349199
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	SUD50P08-25L-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 80V 50A DPAK
Datasheet	SUD50P08-25L-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	80V
Continuous Drain Current at 25°C	50A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	160nC @ 10V
Max Input Capacitance	4700pF @ 40V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	8.3W (Ta), 136W (Tc)
Maximum Rds On at Id,Vgs	25.2 mOhm @ 12.5A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-252, (D-Pak)
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	138791-SUD50P08-25L-E3
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian SUD50P08-25L-E3 CAD Model

Alternative Products

Description

The Vishay MOSFET is a P-channel power MOSFET designed for use in a wide range of electronic applications.

Maximum Drain-Source Breakdown Voltage: 80V
Continuous Drain Current: 50A @ 25°C
Gate-Source Threshold Voltage: 3V @ 250μA
Maximum Gate Charge: 160nC @ 10V
Maximum Input Capacitance: 4700pF @ 40V
Maximum Rds On: 25.2 mOhm @ 12.5A, 10V
Package: TO-252, (D-Pak) case
Dimensions: TO-252-3, DPak (2 Leads + Tab), SC-63
Status: currently active
