The Vishay SUM90P10-19L-E3 is a P-channel MOSFET transistor with a drain-source breakdown voltage of 100V and a continuous drain current of 90A @ 25°C.

• Maximum Rds On at Id,Vgs: 19 mOhm @ 20A, 10V
• Maximum Gate-Source Voltage: ±20V
• Maximum Gate Charge: 326nC @ 10V
• Maximum Input Capacitance: 11100pF @ 50V
• Gate-Source Threshold Voltage: 3V @ 250μA
• Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
• Power Dissipation: 13.6W (Ta), 375W (Tc)
• Operating Temperature Range: -55°C to 175°C (TJ)
• Package: TO-263 (D2Pak) package
• Widely used in: power management applications
