V30100C-E3/4W Vishay V30100C-E3/4W Real Image V30100C-E3/4W real image 2 V30100C-E3/4W real image 3
Same model may have multiple batches, images only for reference.
V30100C-E3/4W Vishay V30100C-E3/4W Real Image V30100C-E3/4W real image 2 V30100C-E3/4W real image 3
V30100C-E3/4W Vishay V30100C-E3/4W Real Image V30100C-E3/4W real image 2 V30100C-E3/4W real image 3
Same model may have multiple batches, images only for reference.

V30100C-E3/4W

Part No V30100C-E3/4W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description Diode Schottky 100V 30A 3-Pin(3+Tab) TO-220AB Tube / DIODE ARRAY SCHOTTKY 100V TO220
Datasheet
V30100C-E3/4W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 15A
Voltage - Forward (Vf) (Max) @ If 800mV @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 100V
Operating Temperature - Junction -40°C to 150°C
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 056970-V30100C-E3/4W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name V30100C
Introduction Date January 18, 2007
ECCN EAR99
Country of Origin China
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian V30100C-E3/4W CAD Model

Description

The V30100C-E3/4W is a Schottky diode from Vishay.

  • Maximum Reverse Voltage: 100V
  • Maximum Forward Voltage: 800mV @ 15A
  • Current Rating: 15A
  • Reverse Leakage Current: 500 microamperes @ 100V
  • Package: TO-220AB
  • Mounting: Through-hole
