VS-20CTQ045STRLPBF Vishay VS-20CTQ045STRLPBF label picture VS-20CTQ045STRLPBF real image
Same model may have multiple batches, images only for reference.
VS-20CTQ045STRLPBF Vishay VS-20CTQ045STRLPBF label picture VS-20CTQ045STRLPBF real image
VS-20CTQ045STRLPBF Vishay VS-20CTQ045STRLPBF label picture VS-20CTQ045STRLPBF real image
Same model may have multiple batches, images only for reference.

VS-20CTQ045STRLPBF

Part No VS-20CTQ045STRLPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 45V D2PAK
Datasheet
VS-20CTQ045STRLPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Reel package
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 45V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Maximum) @ If 760mV @ 20A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 2mA @ 45V
Operating Temperature - Junction -55°C ~ 175°C
Mounting SMD
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Manufacturer Package D2PAK
Win Source Part Number 761742-VS-20CTQ045STRLPBF
Popularity Medium
Supply and Demand Status Balance
Family Name VS-20CTQ045S
Introduction Date April 09, 2010
ECCN EAR99
Country of Origin China
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian VS-20CTQ045STRLPBF CAD Model

Description

The Vishay Semiconductor Diodes Division VS-20CTQ045STRLPBF is a high-performance Schottky diode.

  • Package: TO-263-3, D2Pak
  • Current: 20A
  • Voltage: 45V
  • Recovery Time: 200mA (Io)
  • Forward Voltage Drop: 760mV @ 20A
  • Family: VS-20CTQ045S
  • Manufacturer: Vishay Semiconductor Diodes Division
  • Country of Origin: China
