VS-8EWS08STR-M3 Real Image VS-8EWS08STR-M3 Real Image1 VS-8EWS08STR-M3 Real Image2
Same model may have multiple batches, images only for reference.
VS-8EWS08STR-M3 Real Image VS-8EWS08STR-M3 Real Image1 VS-8EWS08STR-M3 Real Image2
VS-8EWS08STR-M3 Real Image VS-8EWS08STR-M3 Real Image1 VS-8EWS08STR-M3 Real Image2
Same model may have multiple batches, images only for reference.

VS-8EWS08STR-M3

Part No VS-8EWS08STR-M3
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE RECTIFIER 800V 8A DPAK
Datasheet
VS-8EWS08STR-M3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 800V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 8A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 50μA @ 800V
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 1010554-VS-8EWS08STR-M3
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian VS-8EWS08STR-M3 CAD Model

Description

The Vishay standard diode is a high-quality electronic component used in various applications.

  • Voltage Rating: 800V
  • Average Rectified Current (Io): 8A
  • Voltage Forward (Vf) (Max) @ If: 1.1V @ 8A
  • Current Reverse Leakage @ Vr: 50μA @ 800V
  • Operating Temperature: -55°C to 150°C
  • Mounting: Surface mountable
  • Case/Package: D-PAK (TO-252AA)
  • Popularity: Popular
  • Supply and demand status: Sufficient
