1640920000 Weidmuller
Same model may have multiple batches, images only for reference.

1640920000

Part No 1640920000
Manufacturer Weidmuller
Catalog Terminal Blocks
Description TERM BLK 3P SIDE ENT 5.08MM PCB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Weidmüller
Packaging Bulk
Number of Levels 1
Positions Per Level 3
Pitch 0.200" (5.08mm)
Mating Orientation Horizontal with Board
Current 20A
Voltage 300V
Wire Gauge 12-26 AWG
Mounting Style Through Hole
Wire Termination Screw - Clamping Yoke, Tension Sleeve
Features High Wire Entry Level, Interlocking (Front, Side)
Color Orange
Temperature Range - Operating -50°C ~ 100°C
Housing Material Polyamide (PA), Nylon
Contact Material - Plating Copper Alloy - Tin Plated
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Screw Thread M3
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803092-1640920000
Ultra Librarian 3D Model Ultra Librarian 1640920000 CAD Model

Description

The device is packaged in bulk, with a housing material of Polyamide (PA), Nylon, and a color of orange.

  • Housing Material: Polyamide (PA), Nylon
  • Color: Orange
  • Wire Entry: High
  • Features: Interlocking (front, side)
  • Wire Gauge: 12-26 AWG
  • Voltage: 300V
  • Current: 20A
  • Mating Orientation: Horizontal with board
  • Wire Termination: Screw-clamping yoke, tension sleeve
  • Contact Material-Plating: Copper Alloy - Tin Plated
  • Screw Thread: M3
  • Temperature Range: -50°C ~ 100°C
