7445320

Name: 7445320
Brand: Wurth Electronics Inc
SKU: 547310
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	7445320
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	WE-PD3 SMT SHIELDED POWER INDUCT
Datasheet	7445320 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Wurth Electronics Inc
Series	WE-PD3
Package	Tape & Reel
Product Status	Active
Type	Wirewound
Material - Core	Metal Composite
Inductance	100 µH
Tolerance	±20%
Current Rating (Amps)	400 mA
Current - Saturation (Isat)	700mA
Shielding	Shielded
DC Resistance (DCR)	1.4Ohm Max
Frequency - Self Resonant	8MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.500" L x 0.398" W (12.70mm x 10.10mm)
Height - Seated (Max)	0.118" (3.00mm)
Standard Package	1,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	547310-7445320
Ultra Librarian 3D Model	Ultra Librarian 7445320 CAD Model

Alternative Products

Description

The WE-PD3 is a fixed inductor from Wurth Electronics Inc.

Inductor Type: Wirewound
Package Size: 0.500" L x 0.398" W (12.70mm x 10.10mm)
Inductance: 100 µH
DC Resistance (DCR): 1.4 Ohm
Shielded: Yes
Self-Resonant Frequency: 8MHz
Operating Temperature: -40°C to 125°C
