Same model may have multiple batches, images only for reference.

74459115

Name: 74459115
Brand: Wurth Electronics Inc
SKU: 547333
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	74459115
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	FIXED IND 15UH 3.5A 48 MOHM SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Wurth Electronics Inc
Series	WE-PD3
Package	Tape & Reel
Product Status	Active
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	15 µH
Tolerance	±20%
Current Rating (Amps)	3.5 A
Current - Saturation (Isat)	7A
Shielding	Shielded
DC Resistance (DCR)	48mOhm Max
Frequency - Self Resonant	16.5MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.730" L x 0.600" W (18.54mm x 15.24mm)
Height - Seated (Max)	0.300" (7.62mm)
Standard Package	300 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	547333-74459115
Ultra Librarian 3D Model	Ultra Librarian 74459115 CAD Model

Alternative Products

Description

The WE-PD3 series from Wurth Electronics Inc. offers high-quality fixed inductors suitable for various electronic applications.

Inductor Type: Drum Core, Wirewound
Size: 0.730" L x 0.600" W (18.54mm x 15.24mm)
Inductance: 15 µH
Tolerance: ±20%
Shielded: Yes
Package: Tape & Reel
Maximum Seated Height: 0.300" (7.62mm)
DC Resistance (DCR): 48mOhm Max
Current Rating: 3.5 A
Mounting: Surface Mount
Operating Temperature: -40°C to 125°C
