XC3S50A-4TQG144C Real Image XC3S50A-4TQG144C real image9968
Same model may have multiple batches, images only for reference.
XC3S50A-4TQG144C Real Image XC3S50A-4TQG144C real image9968
XC3S50A-4TQG144C Real Image XC3S50A-4TQG144C real image9968
Same model may have multiple batches, images only for reference.

XC3S50A-4TQG144C

Part No XC3S50A-4TQG144C
Manufacturer Xilinx Inc.
Catalog Embedded - FPGAs (Field Programmable Gate Array)
Description FPGA Spartan®-3A Family 50K Gates 1584 Cells 667MHz 90nm Technology 1.2V 144-Pin TQFP EP / IC FPGA 108 I/O 144TQFP
Datasheet
XC3S50A-4TQG144C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Xilinx Inc.
Status Active
Number of LABs/CLBs 176
Number of Logic Elements/Cells 1584
Total RAM Bits 55296
Number of I/O 108
Number of Gates 50000
Supply Voltage - Operating 1.14 V to 1.26 V
Mounting SMD (SMT)
Temperature Range - Operating 0°C to 85°C (TJ)
Case / Package 144-TQFP (20x20)
Win Source Part Number 086819-XC3S50A-4TQG144C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name XC3S50A
Introduction Date December 04, 2006
ECCN EAR99
Country of Origin Singapore, Philippines, Republic of Korea, Taiwan
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian XC3S50A-4TQG144C CAD Model

Description

The XC3S50A-4TQG144C integrated circuit is an SMD (SMT) mounted programmable gate array from Xilinx Inc.

  • I/Os: 108
  • LABs/CLBs: 176
  • Logic Elements/Cells: 1,584
  • Gates: 50,000
  • Total RAM: 55,296 bits
  • Voltage: 1.14 V to 1.26 V
  • Operating Temperature Range: 0°C to 85°C
  • Case/Package: 144-TQFP (20x20)
  • Product Status: Active
  • Estimated EOL Date: 2025
  • Alternative Parts: LFEC1E-5T144I, LFEC1E-3TN144I, LFEC1E-4T144I
  • Supply and Demand Status: Limited
