HF601-40-12 Yamaichi – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HF601-40-12

Part No HF601-40-12
Manufacturer Yamaichi
Catalog FFC, FPC (FlatFlexible) Connector Assemblies
Description CONN FFC VERT 40POS 0.5MM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Flat Flex Type FFC, FPC
Mounting Type Surface Mount
Connector/Contact Type Contacts, Vertical - 1 Sided
Number of Positions 40
Pitch 0.020" (0.50mm)
Termination Solder
FFC, FCB Thickness 0.30mm
Height Above Board 0.079" (2.00mm)
Locking Feature Flip Lock
Contact Material Copper Alloy
Contact Finish Gold-Nickel
Housing Material Liquid Crystal Polymer (LCP)
Actuator Material Polyamide (PA9T), Nylon 9T
Features Solder Retention, Zero Insertion Force (ZIF)
Voltage Rating 50V
Temperature Range - Operating -40°C ~ 85°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1625624-HF601-40-12
Ultra Librarian 3D Model Ultra Librarian HF601-40-12 CAD Model
