BAV23A real image17585 BAV23A real image17586 BAV23A Real Image1 BAV23A Real Image2
Same model may have multiple batches, images only for reference.
BAV23A real image17585 BAV23A real image17586 BAV23A Real Image1 BAV23A Real Image2
BAV23A real image17585 BAV23A real image17586 BAV23A Real Image1 BAV23A Real Image2
Same model may have multiple batches, images only for reference.

BAV23A

Part No BAV23A
Manufacturer Yangzhou yangjie electronic co., ltd
Catalog Diodes, Rectifiers - Arrays
Description SOT-23 250V 0.2A Diodes Rectif
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Yangzhou yangjie electronic co., ltd
Package Tape & Reel
Product Status Active
Diode Configuration 1 Pair Common Anode
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) (per Diode) 225mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 200 mA
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 100 nA @ 250 V
Operating Temperature - Junction -65°C ~ 150°C
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23
Base Product Number BAV23
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
Win Source Part Number 569002-BAV23A
Ultra Librarian 3D Model Ultra Librarian BAV23A CAD Model

Description

The BAV23A is a diode rectifier array with a fast recovery time of less than 500ns and a current rating of greater than 200mA.

  • Recovery Time: Less than 500ns
  • Current Rating: Greater than 200mA
  • Mounting: Surface Mount
  • Package: TO-236-3, SC-59, SOT-23-3
  • Maximum DC Reverse Voltage: 200 V
  • Forward Voltage: 1.25 V @ 200 mA
  • Reverse Recovery Time: 50 ns
  • Manufacturer: Yangzhou yangjie electronic co., ltd
  • Product Status: Active
  • Standard Package: 3,000 pcs on tape and reel
  • REACH: Unaffected
  • ECCN: EAR99
  • Application: Diode rectifier
