Same model may have multiple batches, images only for reference.
UMX1N real image
Same model may have multiple batches, images only for reference.

UMX1N

Part No UMX1N
Manufacturer Yangzhou yangjie electronic co., ltd
Catalog Transistors (BJT) - Arrays
Description SOT-363 NPN+NPN 0.2W 0.15A 60V T
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Bipolar Transistor Arrays
Mfr Yangzhou yangjie electronic co., ltd
Package Tape & Reel
Product Status Active
Transistor Type 2 NPN (Dual)
Current - Collector (Ic) (Max) 150mA
Voltage - Collector Emitter Breakdown (Max) 50V
Vce Saturation (Max) @ Ib, Ic 400mV @ 5mA, 50mA
Current - Collector Cutoff (Max) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 1mA, 6V
Power - Max 150mW
Frequency - Transition 180MHz
Temperature Range - Operating -55°C ~ 150°C
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Supplier Device Package SOT-363
Base Product Number UMX1
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
Win Source Part Number 742914-UMX1N
Ultra Librarian 3D Model Ultra Librarian UMX1N CAD Model

Description

The 742914-UMX1N is a bipolar transistor array used in discrete semiconductor products.

  • Manufacturer: Yangzhou yangjie electronic co., ltd
  • Category: Transistors - Bipolar (BJT) - Bipolar Transistor Arrays
  • Status: Active
  • Maximum Power Rating: 150mW
  • Maximum Collector-Emitter Breakdown Voltage: 50V
  • Maximum Collector Current: 150mA
  • Transistor Type: 2 NPN
  • Vce Saturation: 400mV @ 5mA, 50mA
  • Current Cutoff: Maximum 100nA (ICBO)
  • DC Current Gain (hFE): 120 @ 1mA, 6V
  • Frequency Transition: 180MHz
  • Package: Surface Mount
  • Case: 6-TSSOP, SC-88, SOT-363
  • Supplier Device Package: SOT-363
  • Operating Temperature: -55°C to 150°C
  • ECCN: EAR99
  • Counterfeit Risk: 48%
  • REACH Status: Unaffected
