The AIMTEC AM1L-0512DH30-NZ is a compact and efficient DC-DC converter module. It is designed to provide a regulated 3W output from an input voltage of 4.5-9VDC. This module offers a reliable solution for isolating and converting DC power in various applications. The small size and high efficiency make it ideal for integration into space-constrained designs.

Applications:

• Industrial Control Systems: Providing isolated power to sensitive control circuits.
• Instrumentation: Powering measurement and monitoring equipment.
• Telecommunications: Supplying power to communication interfaces.
• Portable Devices: Powering various components in battery-operated devices.
• Medical Equipment: Isolating power supplies for patient safety.

Features:

• 3W Isolated Output: Delivers a stable and isolated 3W power output.
• Input Voltage Range: Operates with a wide input voltage range of 4.5-9VDC.
• Output Voltage: Provides 12VDC output.
• Isolation Voltage: Offers high isolation voltage for safety and noise immunity.
• Compact Size: Small footprint for easy integration into tight spaces.
• High Efficiency: Minimizes power loss and heat generation.
• Short Circuit Protection: Protects the module and connected circuits from damage.
• Overload Protection: Prevents damage due to excessive load.

Benefits:

• Reliable Power Supply: Ensures a stable and isolated power source for critical applications.
• Enhanced Safety: High isolation voltage protects against electrical hazards.
• Improved Noise Immunity: Reduces noise and interference in sensitive circuits.
• Space Saving: Compact size allows for integration into small devices and systems.
• Energy Efficient: High efficiency minimizes power consumption and heat dissipation.
• Protection Features: Built-in protection features ensure reliable operation and prevent damage.

Additional Details:

The AM1L-0512DH30-NZ DC-DC converter module is designed for through-hole mounting. It is RoHS compliant and meets industry safety standards. The module’s robust design and comprehensive protection features ensure long-term reliability in demanding environments. Its efficiency typically exceeds 80%, minimizing heat generation and maximizing power delivery to the load. The isolation voltage is rated at 1500VDC, providing excellent protection against ground loops and voltage transients.
