The ACS764XLFTR-16AU-T is a fully integrated, Hall effect-based linear current sensor IC manufactured by Allegro MicroSystems. It is designed to provide accurate AC or DC current sensing for industrial, automotive, commercial, and communications systems. The device is available in a small surface mount SOIC-16 wide body package and offers enhanced isolation.

Applications:

• Motor control.
• Load detection and management.
• Switched-mode power supplies.
• Overcurrent fault protection.
• Automotive systems (e.g., electric power steering, braking systems).
• Solar inverters.

Features:

• Low noise analog signal path.
• Fixed gain.
• SOIC-16 wide body package.
• 5 V single supply operation.
• 120 kHz bandwidth.
• Ratiometric output from supply voltage.
• Enhanced isolation voltage.

Benefits:

• Provides accurate current sensing for motor control and power management.
• Simplifies design with a fully integrated solution.
• Reduces system cost with a single-chip solution.
• Enhances safety with overcurrent fault detection.
• Improves system performance with low noise and high bandwidth.
• Offers flexibility with ratiometric output.
• Provides robustness with enhanced isolation.

Additional Details:

The ACS764XLFTR-16AU-T utilizes Hall-effect technology to precisely measure the magnetic field generated by the current flowing through the integrated conductor. This allows for non-intrusive current sensing, eliminating the need for external sense resistors and reducing power losses. The device's SOIC-16 wide body package provides improved creepage and clearance compared to standard SOIC packages, enhancing safety and reliability in high-voltage applications.

The device operates from a single 5 V supply and provides a ratiometric output, meaning the output voltage is proportional to the supply voltage, which reduces the impact of supply voltage variations on accuracy. Its wide bandwidth enables accurate measurement of high-frequency currents, making it suitable for applications such as switched-mode power supplies and motor control. The ACS764XLFTR-16AU-T is designed for demanding applications and incorporates features to ensure robust performance and reliable operation.
