The MLB05-301-RC is a common mode choke manufactured by Allied Components International. This choke is designed to suppress common mode noise in electronic circuits. It's crucial for reducing electromagnetic interference (EMI) and ensuring signal integrity in sensitive applications.

Applications:

• Power line filtering
• USB data lines
• Signal lines in communication equipment
• Audio equipment
• Motor drives

Features:

• High common mode impedance
• Low differential mode impedance
• Compact size
• Wide frequency range
• RoHS compliant

Benefits:

• Effectively suppresses common mode noise
• Minimally affects differential signals
• Saves space on the PCB
• Works across a wide range of frequencies
• Environmentally friendly due to RoHS compliance

Specifications:

Typical specifications for the MLB05-301-RC include an inductance value around 300uH, a rated current of 0.5A, and a DC resistance in the milliohm range. It's designed to operate over a wide frequency range and provides high common mode impedance at the frequencies where noise suppression is needed. Refer to the official Allied Components International datasheet for precise details on impedance vs. frequency characteristics and other parameters.
