AO4838 Real Image AO4838 real image15104 AO4838 Real Image1 AO4838 Real Image2
Same model may have multiple batches, images only for reference.
AO4838 Real Image AO4838 real image15104 AO4838 Real Image1 AO4838 Real Image2
AO4838 Real Image AO4838 real image15104 AO4838 Real Image1 AO4838 Real Image2
Same model may have multiple batches, images only for reference.

AO4838

Part No AO4838
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 30V 11A 8SOIC
Datasheet
AO4838 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 11A
Maximum Rds On at Id,Vgs 9.6 mOhm @ 11A, 10V
Gate-Source Threshold Voltage 2.6V @ 250μA
Max Gate Charge 22nC @ 10V
Max Input Capacitance 1300pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1016814-AO4838
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AO4838 CAD Model

Description

The AO4838 is a dual N-channel FET manufactured by Alpha & Omega Semiconductor Inc.

  • Mounting Type: SMD (SMT)
  • Power Dissipation (Max): 2W
  • Voltage - Drain Source Breakdown (Vdss): 30V
  • Continuous Drain Current (Id) @ 25°C: 11A
  • Voltage - Gate Threshold (Vgs(th)) (Max) @ Id: 2.6V @ 250μA
  • Gate Charge (Qg) (Max) @ Vgs: 22nC @ 10V
  • Input Capacitance (Ciss) (Max) @ Vds: 1300pF @ 15V
  • Rds On (Max) @ Id, Vgs: 9.6 mOhm @ 11A, 10V
